MOSFET 选型指南

Low Voltage

N-Channel SGT MOSFET(25V-250V)

N-Channel Trench MOSFET(8V-200V)

P-Channel Trench MOSFET(8V-200V)

全部

High Voltage

N-Channel Planar MOSFET(200V-1000V)

N-Channel Superjunction MOSFET(500V-900V)

全部

封装

BVDss(V)

-40(v)1 000(v)-40(v)1 000(v)-40(v) — 1 000(v)

（V）

—

（V）

Id(A)

-85(A)180(A)-85(A)180(A)-85(A) — 180(A)

（A）

—

（A）

RDS(Ω)

0.0 001(Ω)540(Ω)0.0 001(Ω)540(Ω)0.0 001(Ω) — 540(Ω)

（Ω）

—

（Ω）

MOSFET-High Voltage-全部

(133)

排序方式

清空条件

Part Number	BVDSS_V	ID_A	RDS_ON	Qg_nC	Package	Type
SW20N20D	200.00	20.00	0.16	37	TO-251,TO-252	00
SW640M	200.00	20.00	0.15	19	TO-220	00
SW20N20M	200.00	20.00	0.14	20	TO-252	00
SW640D	200.00	18.00	0.15	38	TO-220,TO-220FT,TO-263	00
SW630D	200.00	9.00	0.27	20	TO-220,TO-252	00
SW630M	200.00	9.00	0.29	12	TO-220,TO-252	00
SW5N25K3	250.00	5.00	0.5	3.6	TO-252	00
SW740M	400.00	11.00	0.52	24	TO-220F	00
SW740D	400.00	10.00	0.4	35	TO-220,TO-220F,TO-252	00
SW2N40M	400.00	1.00	9	2.8	SOT-23	00
SW20N50B	500.00	20.00	0.2	52	TO-220F,TO-247	00
SW20N50D	500.00	20.00	0.19	82	TO-220F,TO-247	00
SW18N50M	500.00	18.00	0.25	70	TO-220F	00
SW18N50D	500.00	18.00	0.24	88	TO-220F,TO-247	00
SW15N50D	500.00	15.00	0.22	92	TO-220SF	00
SW13N50M	500.00	13.00	0.4	36	TO-220F	00
SW13N50D	500.00	13.00	0.46	47	TO-220,TO-220F	00
SW9N50D	500.00	9.00	0.68	31	TO-220,TO-220F,TO-252	00
SW9N50M	500.00	9.00	0.7	23	TO-220F,TO-252	00
SW830M	500.00	5.00	1.26	14	TO-252	00
SW830D1	500.00	5.00	1.33	17	TO-220,TO-251,TO-252,TO-220F	00
SW40N60K3F	600.00	40.00	0.071	58	TO-220F	00
SW72N60K3F	600.00	72.00	0.032	123	TO-247	00
SW48N60K3F	600.00	48.00	0.0575	69	TO-220F,TO-247	00
SW100N60K3F	600.00	100.00	0.019	200	TO-247	00
SW45N60K2F	600.00	45.00	0.065	74	TO-247	00
SW45N60K2	600.00	45.00	0.06	74	TO-247	00
SW20N60K	600.00	20.00	0.15	60	TO-220F	00
SW16N60K	600.00	16.00	0.21	43	TO-220F	00
SW6N60K	600.00	6.00	0.72	17	TO-220F	00
SW4N60TF	600.00	4.00	2.2	17	TO-252	00
SW10N60D	600.00	10.00	0.9	35	TO-220F	00
SW7N60D	600.00	7.00	1.05	30	TO-220F,TO-220,TO-251,TO252	00
SW4N60M	600.00	4.00	2	13.5	TO-252,TO-220F	00
SW4N60D	600.00	4.00	1.9	18	TO-220F,TO-220FT,TO-251,TO-251S,TO-251M,TO-252	00
SW2N60DB	600.00	2.00	3.9	10	TO-220F	00
SW1N60M	600.00	1.00	7.7	6	TO-92,SOT-223	00
SW1N60DC	600.00	1.00	7	7	TO-252,SOT-223	00
SW601Q	600.00	0.02	540	null	SOT-23	00
SW1N60D	600.00	1.00	6.6	6.8	TO-251,TO-92,TO-251S	00
SW11N65KL4	650.00	11.00	0.33	20	TO-252	00
SW9N65K3	650.00	9.00	0.45	16	TO-252,TO-220F	00
SW30N65K3F	650.00	30.00	0.092	47	TO-220F	00
SW5N65K3	650.00	5.00	0.8	10	TO-252	00
SW8N65K3	650.00	8.00	0.55	15	TO-220F,TO-252	00
SW35N65KL4F	650.00	35.00	0.095	82	TO-247	00
SW14N65KL4	650.00	14.00	0.24	29	TO-252	00
SW11N65K3	650.00	11.00	0.34	18	TO-252,TO-220F	00
SW70N65KLF	650.00	70.00	0.035	163	TO-247	00
SW20N65KL4	650.00	20.00	0.18	37	TO-252,TO-220F	00
SW20N65K2	650.00	20.00	0.15	37	TO-220F	00
SW20N65KL	650.00	20.00	0.16	40	TO-220F	00
SW13N65K2	650.00	13.00	0.24	28	TO-220F,TO-251,TO-252,TO-220,TO-262N,TO-263,DFN56,QFN88	00
SW14N65KL	650.00	14.00	0.25	21	TO-220F	00
SW11N65KL	650.00	11.00	0.33	23	TO-220F,TO-252,TO-220FT	00
SW7N65KL	650.00	7.00	0.53	17	TO-220F,TO-252	00
SW7N65K2	650.00	7.00	0.57	14.5	TO-220F,TO-251,TO-251N,TO-252	00
SW7N65K	650.00	7.00	0.5	21	TO-220F,TO-220SF,TO-251,TO-251N,TO-252,TO-220	00
SW4N65K2	650.00	4.00	1.1	7.1	TO-220F,TO-251N,TO-252	00
SW4N65K	650.00	4.00	1	13	TO-220F,TO-251,TO-252	00
SW4N65P	650.00	4.00	2	15	TO-220F,TO-252	00
SW16N65M	650.00	16.00	0.43	52	TO-220F	00
SW7N65C	650.00	7.00	1.2	27	TO-252,TO-220F	00
SW18N65B	650.00	18.00	0.46	43	TO-220F	00
SW15N65B	650.00	15.00	0.65	31	TO-220F	00
SW20N65D	650.00	20.00	0.31	88	TO-220F,TO-220FTN,TO-247	00
SW20N65M	650.00	20.00	0.32	77	TO-220F	00
SW18N65M	650.00	18.00	0.35	64	TO-220F	00
SW18N65D	650.00	18.00	0.35	79	TO-220F,TO-247	00
SW16N65D	650.00	16.00	0.46	68	TO-220F	00
SW15N65D	650.00	15.00	0.57	57	TO-220F	00
SW12N65D	650.00	12.00	0.66	null	TO-220SF,TO220FT	02
SW12N65D	650.00	12.00	0.7	null	TO-220F,TO-262,TO-220,TO-263	01
SW10N65D	650.00	10.00	0.9	35	TO-220F,TO-220SF,TO-220FT,TO-220,TO-262N	00
SW14N65M	650.00	14.00	0.56	44	TO-220F	00
SW12N65M	650.00	12.00	0.68	37	TO-220F,TO-220FT	00
SW10N65M	650.00	10.00	0.9	29	TO-220F,TO-220FT	00
SW8N65MA	650.00	8.00	1.04	29	TO-252,TO-251	00
SW8N65M	650.00	8.00	0.88	32	TO-252,TO-251,TO-262N	00
SW8N65B	650.00	8.00	0.7	27	TO-252	00
SW7N65M	650.00	7.00	1.2	23	TO-251N,TO-252,TO-220F,TO-220FTN,DFN5*6	00
SW7N65DA	650.00	7.00	1.4	25	TO-251N,TO-262N,TO-252	00
SW7N65D	650.00	7.00	1.1	30	TO-220,TO-251,TO-251N,TO-251U,TO-252	00
SW6N65D	650.00	6.00	1.3	22	TO-252	00
SW4N65M	650.00	4.00	2.1	15	TO-220F,TO-220FTN,TO-251N,TO-252,TO-251S	00
SW4N65DD	650.00	4.00	2.4	16	TO-251N,TO251N-S2,TO-220F,TO-220SF,TO-252,TO-220FTN	00
SW4N65D	650.00	4.00	2	18	TO-220F,TO-251N,TO-251S,TO-251M,TO-251U...	00
SW2N65B	650.00	2.00	4.2	8.5	TO-220F,TO-252,TO-251S	00
SW2N65DB	650.00	2.00	3.9	11	TO-220F	00
SW7N70KL	700.00	7.00	0.45	18	TO-252	00
SW13N70KL	700.00	13.00	0.32	26	TO-252	00
SW15N70J	700.00	15.00	0.22	29	TO-220SF,TO-220F	00
SW4N70K2	700.00	4.00	1.15	7.1	TO-220F,TO-251N,TO-252	00
SW7N70P	700.00	7.00	1.4	23	TO-252	00
SW7N70B	700.00	7.00	1.3	24	TO-262N	00
SW2N70M	700.00	2.00	4	9.5	TO-252	00
SW6N70B	700.00	6.00	1.35	22	TO-220F	00
SW6N70P2	700.00	6.00	1.6	20	TO-252	00
SW16N70D	700.00	16.00	0.54	67	TO-220F	00
SW16N70M	700.00	16.00	0.5	57	TO-220FT	00
SW12N70M	700.00	12.00	0.9	37	TO-220F	00
SW12N70D	700.00	12.00	0.75	47	TO-220F,TO-262,TO-220SF,TO-220FT	00
SW10N70M	700.00	10.00	1.1	30	TO-220F	00
SW7N70D	700.00	7.00	1.2	30	TO-252,TO-251N,TO-262N,TO-220F	00
SW7N70M	700.00	7.00	1.2	28	TO-262N,TO-252,TO-220F	00
SW7N70DA	700.00	7.00	1.5	28	TO-251N	00
SW6N70M	700.00	6.00	1.5	24	TO-251N,TO-252,TO-220F	00
SW6N70DA	700.00	6.00	1.7	26	TO-251,TO-251NX,TO-220,TO-251Q,TO-251MQ	00
SW6N70DB	700.00	6.00	1.4	30	TO-220F,TO-252,TO-251N	00
SW4N70L	700.00	4.00	0.8	18	TO-220F,TO-251N,TO-252	00
SW15N80K3	800.00	15.00	0.21	47	TO-220F	00
SW12N80K3	800.00	12.00	0.3	35	TO-220F	00
SW7N80K3	800.00	7.00	0.54	18	TO-220F,TO-252	00
SW6N80KL	800.00	6.00	0.72	16	TO-220F,TO-252	00
SW10N80K3	800.00	10.00	0.4	42	TO-220F,TO-252	00
SW12N80KL	800.00	12.00	0.37	28	TO-252,TO-220F	00
SW10N80K2	800.00	10.00	0.58	27	TO-220F,TO-251N,TO-252	00
SW7N80P	800.00	7.00	1.45	28	TO-220F	00
SW6N80P	800.00	6.00	2.3	20	TO-252	00
SW10N80M	800.00	10.00	0.86	33	TO-220F	00
SW6N80MA	800.00	6.00	2	27	TO-252	00
SW10N80D	800.00	10.00	1	55	TO-220F	00
SW7N80D	800.00	7.00	1.5	39	TO-220F,TO-262,TO-262N	00
SW7N80M	800.00	7.00	1.23	23	TO-220F,TO-262N	00
SW6N80M	800.00	6.00	2	17	TO-262N,TO-252	00
SW4N80M	800.00	4.00	3.2	12	TO-252,TO-251N	00
SW4N80D	800.00	4.00	3.2	19	TO-220F,TO-251N,TO-252,TO-262N	00
SW3N80D	800.00	3.00	3.8	17	TO-220F,TO-251N,TO-252	00
SW3N90P	900.00	3.00	4.3	15	TO-252	00
SW9N90P	900.00	9.00	1.3	42	TO-220F,TO-3P	00
SW6N90M	900.00	6.00	1.8	21	TO-262N,TO-220F	00
SW6N90D	900.00	6.00	1.8	42	TO-220F,TO-262N	00
