搜索产品数量-(279)
Part Number Vces(V) Ic(A) Qg(nC) Package
SW046R10ES-3 100 135 63 TO-220FB,TO-263
SW046R10ES-2 100 80 64 TO-220F
SW150R10VS 100 43 14.4 TO-252
SW4N65P 650 4 15 TO-220F,TO-252
SW012R10ES 100 325 201 TOLL
SW080R06ET 60 40 43 DFN3*3
SW046R85E8S-3 85 130 56 TO-252
SW16N65M 650 16 52 TO-220F
SW15N80K3 800 15 47 TO-220F
SW12N80K3 800 12 35 TO-220F
SW7N80K3 800 7 18 TO-220F,TO-252
SW043R08ES 80 135 48 TO-263
SW035R10ES 100 180 83 TO-263
SW014R04VLS 40 150 89 DFN5*6
SW046R10ES 100 115 65 DFN5*6
SW036R68E8T 68 150 172 TO-220FB,TO-263
SW22N65K3F 650 22 34 TO-247,TO-220F,TO-252
SW072P03VT -30 -50 45 TO-252
SW072P03VT -30 -45 45 DFN5*6
SW072P03VT -30 -15 45 SOP-8
SW072P03VT -30 -35 45 DFN3*3
SW038R13E8S 135 220 151 TO-263-7
SW7N80P 800 7 28 TO-220F
SW7N65C 650 7 27 TO-252,TO-220F
SW034R10ES 100 180 82 TO-220FB,TO-263
SW036R08ES 80 160 64 TO-220FB
SW042R08ES 80 150 51 TO-220FB
SW043R15E8S 150 200 154 TO-220FB
SW2N70M 700 2 9.5 TO-252
SW5N25K3 250 5 3.6 TO-252
SW6N80KL 800 6 16 TO-220F,TO-252
SW2800R15ES 150 6 5.2 TO-252
SW064R10VLS 100 110 58 TO-252
SW6N70B 700 6 22 TO-220F
SW064R10VLS 100 15 58 SOP-8
SW6N70P2 700 6 20 TO-252
SW30P04 -40 -30 28 TO-252
SW029R68E8T 68 170 277 TO-220FB
SW3N90P 900 3 15 TO-252
SW9N90P 900 9 42 TO-220F,TO-3P
SW030R68E8T 68 160 262 TO-220FB
SW030R10E8S 100 230 114 TOLL
SW6N80P 800 6 20 TO-252
SW038R13E8S 135 200 156 TO-220FB,TO-263
SW050R06VLS 60 70 32 DFN5*6
SW48N60K3F 600 48 69 TO-220F
SW023R04VLT 40 180 206 TO-220FB,TO-263
SW5N65K3 650 5 10 TO-252
SW8N65K3 650 8 15 TO-220F,TO-252
SW023R04VLT 40 120 198 DFN5*6
SW030R85E8S 85 150 85 TO-252
SW100N60K3F 600 100 200 TO-247
SW120R06VLS 60 60 18 TO-220FB
SW120R06VLS 60 55 18 TO-251S,TO-252
SW064R10VLS 100 95 58 DFN5*6
SW047R04VLT 40 60 91 DFN5*6
SW35N65KL4F 650 35 82 TO-247
SW023R85E8S 85 200 125 TO-220FB,TO-263
SW18N65B 650 18 43 TO-220F
SW14N65KL4 650 14 29 TO-252
SW11N65K3 650 11 18 TO-252,TO-220F
SW15N65B 650 15 31 TO-220F
SW10N80M 800 10 33 TO-220F
SW10N80K3 800 10 42 TO-220F,TO-252
SW6N90M 900 6 21 TO-262N,TO-220F
SW6N80MA 800 6 27 TO-252
SW210R06VLS 60 30 9.7 TO-252,TO-251S
SW210R06VLS 60 30 9.8 TO-220FB
SW210R06VLS 60 8 10 SOP-8
SW70N65KLF 650 70 163 TO-247
SW026R04VLT 40 145 43 TO-220FB
SW20N65KL4 650 20 37 TO-252,TO-220F
SW016R03VLT 30 180 205 TO-220FB
SW6N90D 900 6 42 TO-220F,TO-262N
SW12N80KL 800 12 28 TO-252,TO-220F
SW10N80K2 800 10 27 TO-220F,TO-251N,TO-252
SW10N80D 800 10 55 TO-220F
SW7N80D 800 7 39 TO-220F,TO-262,TO-262N
SW7N80M 800 7 23 TO-220F,TO-262N
SW6N80M 800 6 17 TO-262N,TO-252
SW4N80M 800 4 12 TO-252,TO-251N
SW4N80D 800 4 19 TO-220F,TO-251N,TO-252,TO-262N
SW3N80D 800 3 17 TO-220F,TO-251N,TO-252
SW16N70D 700 16 67 TO-220F
SW16N70M 700 16 57 TO-220FT
SW15N70J 700 15 29 TO-220SF,TO-220F
SW12N70M 700 12 37 TO-220F
SW12N70D 700 12 47 TO-220F,TO-262,TO-220SF,TO-220FT
SW10N70M 700 10 30 TO-220F
SW7N70D 700 7 30 TO-252,TO-251N,TO-262N,TO-220F
SW7N70M 700 7 28 TO-262N,TO-252,TO-220F
SW7N70DA 700 7 28 TO-251N
SW6N70M 700 6 24 TO-251N,TO-252,TO-220F
SW6N70DA 700 6 26 TO-251,TO-251NX,TO-220,TO-251Q,TO-251MQ
SW6N70DB 700 6 30 TO-220F,TO-252,TO-251N
SW4N70L 700 4 18 TO-220F,TO-251N,TO-252
SW4N70K2 700 4 7.1 TO-220F,TO-251N,TO-252
SW20N65D 650 20 88 TO-220F,TO-220FTN,TO-247
SW20N65K2 650 20 37 TO-220F
SW20N65M 650 20 77 TO-220F
SW20N65KL 650 20 40 TO-220F
SW18N65M 650 18 64 TO-220F
SW18N65D 650 18 79 TO-220F,TO-247
SW16N65D 650 16 68 TO-220F
SW15N65D 650 15 57 TO-220F
SW13N65K2 650 13 28 TO-220F,TO-251,TO-252,TO-220,TO-262N,TO-263,DFN5*6,QFN8*8
SW12N65D 650 12 TO-220SF,TO220FT
SW12N65D 650 12 TO-220F,TO-262,TO-220,TO-263
SW10N65D 650 10 35 TO-220F,TO-220SF,TO-220FT,TO-220,TO-262N
SW14N65M 650 14 44 TO-220F
SW14N65KL 650 14 21 TO-220F
SW12N65M 650 12 37 TO-220F
SW11N65KL 650 11 23 TO-220F,TO-252,TO-220FT
SW10N65M 650 10 29 TO-220F,TO-220FT
SW8N65MA 650 8 29 TO-252,TO-251
SW8N65M 650 8 32 TO-252,TO-251,TO-262N
SW8N65B 650 8 27 TO-252
SW7N65M 650 7 23 TO-251N,TO-252,TO-220F,DFN5*6
SW7N65KL 650 7 17 TO-220F,TO-252
SW7N65DA 650 7 25 TO-251N,TO-262N,TO-252
SW7N65D 650 7 30 TO-220,TO-251,TO-251N,TO-251U,TO-252
SW7N65K2 650 7 14.5 TO-220F,TO-251,TO-251N,TO-252
SW7N65K 650 7 21 TO-220F,TO-220SF,TO-251,TO-251N,TO-252,TO-220
SW6N65D 650 6 22 TO-252
SW4N65M 650 4 15 TO-220F,TO-251N,TO-252,TO-220FTN
SW4N60TF 600 4 17 TO-252
SW4N65DD 650 4 16 TO-251N,TO251N-S2,TO-220F,TO-220SF,TO-252,TO-220FTN
SW4N65D 650 4 18 TO-220F,TO-251N,TO-251S,TO-251M,TO-251U
SW4N65K2 650 4 7.1 TO-220F,TO-251N,TO-252
SW4N65K 650 4 13 TO-220F,TO-251,TO-252
SW2N65B 650 2 8.5 TO-220F,TO-252
SW2N65DB 650 2 11 TO-220F
SW45N60K2F 600 45 74 TO-247
SW45N60K2 600 45 74 TO-247
SW20N60K 600 20 60 TO-220F
SW16N60K 600 16 43 TO-220F
SW10N60D 600 10 35 TO-220F
SW7N60D 600 7 30 TO-220F,TO-220,TO-251,TO252
SW6N60K 600 6 17 TO-220F
SW4N60M 600 4 13.5 TO-252,TO-220F
SW4N60D 600 4 18 TO-220F,TO-220FT,TO-251,TO-251S,TO-251M,TO-252
SW2N60DB 600 2 10 TO-220F
SW1N60M 600 1 6 TO-92,SOT-223
SW1N60DC 600 1 7 TO-252,SOT-223
SW601Q 600 0.02 SOT-23
SW20N50B 500 20 52 TO-220F,TO-247
SW20N50D 500 20 82 TO-220F,TO-247
SW18N50M 500 18 70 TO-220F
SW18N50D 500 18 88 TO-220F,TO-247
SW15N50D 500 15 92 TO-220SF
SW13N50M 500 13 36 TO-220F
SW13N50D 500 13 47 TO-220,TO-220F
SW9N50D 500 9 31 TO-220,TO-220F,TO-252
SW9N50M 500 9 23 TO-220F,TO-252
SW830M 500 5 14 TO-252
SW830D1 500 5 17 TO-220,TO-251,TO-252,TO-220F
SW740M 400 11 24 TO-220F
SW740D 400 10 35 TO-220,TO-220F,TO-252
SW2N40M 400 1 2.8 SOT-23
SW20N20D 200 20 37 TO-251,TO-252
SW640M 200 20 19 TO-220FB
SW20N20M 200 20 20 TO-252
SW640D 200 18 38 TO-220,TO-220FT,TO-263
SW630D 200 9 20 TO-220,TO-252
SW630M 200 9 12 TO-220,TO-252
SW058R15E8S 150 160 163 TO-220,TO-263
SW051R03VLT 30 85 43 TO-252
SW020R10E8S 100 270 162 TOLL
SW020R10E8S 100 240 164 TO-263,TO-220FB,TO-263-7L
SW030R10E8S 100 190 125 TO-220,TO-263,TO-263-7L
SW036R10E8S 100 175 85 TO-220,TO-263,TO-263-7L
SW038R10VS 100 150 70 TO-220FB
SW050R10E8S 100 140 51 TO-220
SW050R95E8S 100 130 50 TO-220,TO-263
SW038R10VS 100 128 71 DFN5*6
SW050R95E8S 100 110 48 PTO-252
SW050R95E8S 100 100 48 TO-252
SW050R95E8S 100 95 50 DFN5*6
SW072R10VS 100 80 49 DFN5*6
SW230R10VS 100 45 15 TO-220FB
SW230R10VS 100 40 15 TO-252
SW072R10VS 100 13 49 SOP-8
SW010R85E8S 85 350 179 TOLL
SW030R85E8S 85 180 86 TO-220FB,TO-263
SW046R85E8S 85 150 48 PTO-252
SW046R85E8S 85 140 55 TO-220,TO-263
SW054R85E8S 85 130 45 TO-220FB,TO-263
SW050R85E8S 85 130 47 TO-220,TO-263
SW050R85E7S 85 130 77 TO-263
SW050R85E7S 85 130 77 TO-220
SW050R85E8S 85 100 44 DFN5*6
SW046R08E9T 80 160 182 TO-220,TO-263
SW046R08E8T 80 150 183 TO-220,TO-263
SW062R08E8T 80 125 137 TO-220,TO-263
SW062R08E8T 80 110 141 TO-252
SW068R08E8T 80 106 130 TO-220
SW070R08E7T 80 100 109 TO-220
SW068R08E8T 80 100 128 TO-252
SW078R08E8T 80 95 92 TO-252
SW070R08E7T 80 95 101 TO-252
SW078R08E8T 80 95 98 TO-220,TO-263
SW075R08E7T 80 90 95 TO-220,TO-263
SW088R08E8T 80 80 89 TO-220,TO-263
SW088R08E8T 80 80 86 TO-252
SW058R75E7T 75 100 107 TO-220
SW058R72E7T 72 100 107 TO-220
SW058R72E7T 72 100 109 TO-252
SW046R68E8T 68 145 145 TO-220,TO-263
SW050R68E8T 68 130 129 TO-220
SW046R68E8T 68 120 146 TO-252
SW056R68E7T 68 120 107 TO-220,TO-263
SW060R68E7T 68 110 94 TO-220,TO-263
SW055R68E7T 68 110 94 TO-220,TO-263
SW066R68E7T 68 100 85 TO-220
SW062R68E7T 68 100 85 TO-220,TO-263
SW056R68E7T 68 100 102 TO-252
SW065R68E7T 68 100 75 TO-220,TO-263
SW068R68E7T 68 90 78 TO-220,TO-263
SW068R68E7T 68 90 87 TO-252
SW065R68E7T 68 90 75 TO-252
SW076R68E7T 68 85 70 TO-220,TO-263
SW060R65E7T 65 110 94 TO-220,TO-263
SW050R68E8T 68 110 130 TO-252
SW062R68E7T 68 100 102 TO-252
SW056R68E7T 68 100 99 DFN5*6
SW050R68E8T 68 90 127 DFN5*6
SW076R68E7T 68 85 80 TO-252
SW062R68E7T 68 85 100 DFN5*6
SW046R68E8T 68 80 144 DFN5*6
SW085R68E7T 68 75 47 TO-263,TO-220
SW086R68E7T 68 75 64 TO-220,TO-263
SW068R68E7T 68 75 91 DFN5*6
SW085R68E7T 68 70 47 TO-252
SW086R68E7T 68 70 66 TO-252
SW076R68E7T 68 70 78 DFN5*6
SW030R06VLS 60 130 68 TO-252
SW030R06VLS 60 110 70 DFN5*6
SW052R06VS 65 90 32 DFN5*6
SW085R06V7T 60 80 66 TO-220
SW083R06VLS 60 65 22 TO-251
SW083R06VLS 60 50 22 DFN5*6
SW350R06VT 60 24 21 TO-251,TO-252
SW350R06VT 60 10 21 SOP-8
SW083R06VLS 60 10 22 SOP-8
SW023R04VLT 40 160 195 TO-252
SW026R04VLT 40 140 153 TO-252
SW030R04VLT 40 130 139 TO-220,TO-263
SW030R04VLT 40 120 141 TO-252
SW047R04VLT 40 100 92 TO-252
SW030R04VLT 40 90 143 DFN5*6
SW015R03VLT 30 250 315 TO-263
SW020R03VLT 30 180 140 TO-220,TO-263
SW016R03VLT 30 180 201 TO-252
SW017R03VLT 30 160 150 TO-252
SW016R03VLT 30 130 201 DFN5*6
SW018R03VLT 30 120 153 DFN5*6
SW020R03VLT 30 120 145 TO-252
SW025R03VLT 30 115 89 TO-252
SW030R03VLT 30 110 79 TO-252
SW020R03VLT 30 110 143 DFN5*6
SW040R03VLT 30 105 58 TO-220FB,TO-263
SW025R03VLT 30 100 90 DFN5*6
SW040R03VLT 30 100 59 TO-252
SW030R03VLT 30 90 80 DFN5*6
SW040R03VLT 30 70 59 DFN5*6
SW065R03VLT 30 70 33 TO-252
SW040R03VLT 30 65 59 DFN3*3
SW065R03VLT 30 58 34 DFN5*6
SW065R03VLT 30 58 34 DFN3*3
SW040R03VLT 30 19 56 SOP-8
SW065R03VLT 30 14 35 SOP-8
SW028R02VLT 20 90 107 DFN3*3
SW8205 20 6 5.2 SOT23-6
SW165R02VLT 20 6 7 TSSOP-8
SW028P04VT -40 -40 52 TO-252
SW028P04VT -40 -7.5 60 SOP-8
SW028P04 -40 -7.5 48 SOP-8
SW380P03V7T -30 -4.3 21 SOT-23
SW1N60D 600 1 6.8 TO-251,TO-92,TO-251S
